2
The AT-FS709FC Series Fast Ethernet Switch is easy to install and requires
no software management.
The AT-FS709FC Series Fast Ethernet Switch is available with a variety of
fiber optic connectors. For a complete list of the available models, contact your
Allied Telesyn sales representative.
Figure 2 illustrates the AT-FS709FC Series Fast Ethernet Switch.
Figure 2 AT-FS709FC Series Fast Ethernet Switch
10BASE-T / 100BASE-TX 8 PORT FAST ETHERNET SWITCH WITH 100FX UPLINK
1X 8MDI
OR
2X 3X 4X 5X 6X 7X
9
8MDI-X POWER
LINK/ACT
100M
FDX
1 2 3 4 5 6 7 8 9
FS709FC
100-240V 50-60Hz 0.3A
10Base-T/100Base-TX 100Base-FX
Fiber Optic
System and
Port LEDs Twisted Pair Ports
Port
AC Power
Connector
