AT-FS709FC Series Installation Guide
11
Network Topologies
AT-FS709FC Series Ethernet switch supports a variety of network topologies.
The first topology shown in Figure 3 is of a power workgroup. Each end node is
connected directly to a port on an AT-FS709FC switch, giving each node a
dedicated 10 Mbps or 100 Mbps link.
Figure 3 Power Workgroup Topology
10BASE-T / 100BASE-TX 8 PORT FAST ETHERNET SWITCH WITH 100FX UPLINK
1X 8MDI
OR
2X 3X 4X 5X 6X 7X
9
8MDI-X POWER
LINK/ACT
100M
FDX 1 2 3 4 5 6 7 8 9
FS709FC
100 Mbps
10 Mbps
AT-FS709FC
