PN 613-50381-00 Rev A 8 Allied Telesyn, Inc.
Smart
MissingLink
Like MissingLink, the Smart MissingLink feature terminates the link on
the failed port thereby notifying you when a connection has been lost.
Additionally, Smart MissingLink indicates on which port the connection
has failed. This is shown by a blinking LK LED on the good port.
For example, if the network twisted pair cable to the 1000Base-T port on
the media converter were to fail, the LK LED on the 1000Base-X fiber
optic port will blink, indicating a failed connection on the twisted pair
port. The fiber optic port is still able to receive a signal.
The switch notifies the end-node connected to the fiber optic port that
the connection on the twisted pair port has been lost. If the failure had
started with the fiber optic cabling, the LK LED on the twisted pair port
would blink.
The value to this type of network monitoring and fault notification is so
that you can quickly see which port has failed and troubleshoot your
network accordingly.
Cable Specifications
Twisted Pair Port
Table 4 lists the cabling specifications for the 1000Base-T twisted pair
port.
Table 4 1000Base-T Twisted Pair Specifications
Fiber Optic Port
Refer to the AT-G8SX and AT-G8LX GBIC Transceivers Installation
Guide for the cabling and fiber optic port specifications. This guide is
available from the Allied Telesyn web site at
www.alliedtelesyn.com .
Allied Telesyn, Inc. ! 960 Stewart Drive, Suite B ! Sunnyvale, CA 94085 USA
Tel (408) 730-0950 ! Fax (408) 736-0100 ! Technical Support Tel 1-800-428-4835 ! Fax 1 (425) 481-3790
Copyright

2002 Allied Telesyn, Inc. All rights reserved. No part of this publication may be reproduced without prior written
permission from Allied Telesyn, Inc.
Connector Cable Maximum Distance
RJ-45 Shielded or unshielded twisted
pair Category 5 or better 550 m (1,804 ft)
