PN 613-50381-00 Rev A 2 Allied Telesyn, Inc.
The Allied Telesyn certified GBIC transceivers available for use with the
AT-PB1005G media converter are listed below:
For installation instructions for the AT-PB1005G module, refer to the
PowerBlade PBC18 Installation Guide. For a complete description of
the functions and features of the GBIC transceivers and for installation
instructions, refer to the AT-G8SX and AT-G8LX GBIC Transceivers
Installation Guide. Both guides are available from the Allied Telesyn
web site at
www.alliedtelesyn.com .
See Figure 1 for an illustration of the AT-PB1005G Gigabit Ethernet
Media Converter.
Figure 1 AT-PB1005G Gigabit Ethernet Media Converter
❑ AT-G8SX ❑ AT-G8LX40
❑ AT-G8LX10 ❑ AT-G8LX70
❑ AT-G8LX25
Port Status LEDs
1000Base-X Port
(GBIC expansion slot)
1000Base-T Port
(RJ-45 connector)
Module Status LEDs
1000B
ASE-
T
1000B
ASE-X
RX
LK AT
LT SML ML
PR
CLASS 1
LASER PRODUCT
DO NOT STARE
INTO BEAM
TX
PB1005G
1000Mbps
LK AT
MODE
Port Status LEDs
Mode Selection
Push Button
