PN 613-50381-00 Rev A 3 Allied Telesyn, Inc.
Table 1 lists the connector types and cabling distances for the
AT-PB1005G module and the GBIC transceivers.
Table 1 Maximum Operating Distances
For fiber optic cabling specifications for the GBIC transceivers, refer to
the AT-G8SX and AT-G8LX GBIC Transceivers Installation Guide.
Features
The AT-PB1005G media converter has the following features:
❑ LEDs for unit and port status
❑ 1000Base-T twisted pair port with a maximum operating distance
of 550 meters (1,804 feet)
❑ Expansion slot for an 1000Base fiber optic GBIC transceiver with a
maximum operating distance of 220 meters (721 feet) to 70
kilometers (43.4 miles), depending on the model and type of fiber
optic cable used
❑ Full-duplex operation on both ports
❑ Mode selection button to toggle between Link Test, Smart
MissingLink, and MissingLink
Port Connector Maximum Distance
1000Base-T RJ-45 550 m (1,804 ft)
1000Base-SX
AT-G8SX SC 220 m (721 ft)
1
1. Using 62.5/125 micron multimode fiber optic cable.
500 m (1,640 ft)
2
2. Using 50/125 micron multimode fiber optic cable.
1000Base-LX
AT-G8LX10 SC 10 km (6.2 mi)
3
3. Using 10/125 micron single-mode fiber optic cable.
AT-G8LX25 SC 25 km (15.5 mi)
3
AT-G8LX40 SC 40 km (24.8 mi)
3
AT-G8LX70 SC 70 km (43.4 mi)
3
