PN 613-50381-00 Rev A 4 Allied Telesyn, Inc.
Status LEDs
Table 2 list the status LEDs.
Table 2 AT-PB1005G Status LEDs
Twisted Pair Port
The 1000Base-T port on the AT-PB1005G media converter has an RJ-45
connector and is designed to operate with Category 5 or better shielded
or unshielded twisted pair cable.
An RJ-45 twisted pair port on a 1000 Mbps Ethernet network device can
have one of two possible wiring configurations: MDI or MDI-X. The RJ-45
port on a PC, router, or bridge is typically wired as MDI, while the twisted
pair port on a switch or hub is usually MDI-X.
To connect two network devices that have dissimilar wiring
configurations, such as MDI to MDI-X, you use a straight-through twisted
pair cable. To connect two network devices that have the same wiring
configuration, such as MDI to MDI, you use a crossover cable.
The AT-PB1005G media converter features automatic MDI/MDI-X. Each
port automatically determines the configuration of the port on the
device to which it is connected and then configures itself appropriately.
For example, if a port on a media converter is connected to a port on a
bridge, which is typically wired as MDI, the port on the media converter
automatically configures itself as MDI-X. This feature allows you to use
either straight-through or crossover cables when connecting devices to
the media converter. This eliminates the need for a cross-over cable.
LED Color Description
PR Green Power is applied to the media converter.
AT Green Data is being received or transmitted on the port.
LK Green A link has been established on the port.
Mode Status
LT Green Link test is enabled.
SML Green Smart MissingLink is enabled.
ML Green MissingLink is enabled.
