11
Chapter 2
Installation
Before You Begin
.
Note
Installation of this product should only be performed by TRAINED
SERVICE PERSONNEL.
Power
Requirements
Be sure that the voltage and frequency is either 100-120 or 200-240 VAC and
50 or 60 Hz. Since there is no external power switch, power is applied when the
power cord is connected.
Installing the Hub
Making UTP Port Connections
1. Carefully remove the AT-MR840TF hub from its packaging box. Keep the
packing materials for future use.
2. Position the hub in a location with adequate ventilation and a power
source.
3. Attach an AC cord to the hub and make sure that the POWER LED on the
front panel lights.
4. On the hub side, attach your 10Base-T UTP cables (RJ45 connectors) to the
10Base-T ports.
5. On the workstation side, attach the other end of the UTP cable to the
10Base-T network adapter card on the workstation.
