Allied Telesyn AT-VIEW PLUS
DEVICE MANAGER
PN 613-50504-00 Rev C Page 82 of 121
In Polling / Polling Stopped
Status of polling. "In Polling" or "Polling Stopped".
Absolute Value / Per Sample / Per Second
Indicates how data is displayed.
Index
Value of etherStatsIndex of the RMON Statistics group.
Data Source
Value of etherStatsDataSource of the RMON Statistics group.
Owner
Value of etherStatsOwner of the RMON Statistics group.
Status
Value of etherStatsStatus of the RMON Statistics group.
7.2.3 Entry Tab
In the Entry tab, you can select and control the table entry displayed. Data collected by the selected
entry is shown in the Table, Plot Chart and Pie Chart tabs. By default, the entry with the lowest
index number is selected. In this tab, you can also add, remove or edit the entries.
Topics:
• Available Control Table Entries
• Select Button
• Add Button
• Edit Button
• Remove Button
