Allied Telesyn AT-VIEW PLUS
DEVICE MANAGER
PN 613-50504-00 Rev C Page 71 of 121
: Updates the MIB Value fields of the selected variables. To select a variable, click the MIB
Variable field of the target variable.
6.4.8 Set MIB Value Button
: Changes the values of the checked variables, using the SNMP Set operation. The values in the
MIB Value fields are sent to the SNMP agent on the device.
6.4.9 Threshold Button
: Set a threshold on the selected variable. The threshold is used to monitor the variable's value. If
the threshold is exceeded, the action configured on the Options menu is executed. To select a
variable, click the MIB Variable field of the target variable. When you click the Threshold button,
the Edit Threshold Item dialog box appears.
Edit Threshold Item dialog box
The MIB Variable field shows the selected variable name.
To set a threshold, enter a threshold value in the Value field, then click OK. Note that this specifies a
rising threshold which triggers an event when the variable's value increases to exceed the threshold,
i.e. crosses the threshold from below.
When the threshold is reached, a pop-up message is displayed or a predefined command is executed.
You can select which action is executed in the Option > Option > User Action tab.
Note - Thresholds can only be used for variables of type GAUGE, INTEGER, COUNTER,
GAUGE32, INTEGER32, COUNTER32, or COUNTER64.
6 MIB Variable Windows
