Back-to-Back Topology
Figure 5 illustrates two media converters in a back-to-back configuration.
Figure 5 Back-to-Back Topology
TX RX
AT-LMC100SC FAST ETHERNET MEDIA CONVERTER
CLASS 1 LASER PRODUCT DO NOT STARE INTO BEAM
100Base-FX 100Base-TX
PWR
LNK
ACT
LNK
ACT MDI-X
MDI
TX RX
AT-LMC100SC FAST ETHERNET MEDIA CONVERTER
CLASS 1 LASER PRODUCT DO NOT STARE INTO BEAM
100Base-FX 100Base-TX
PWR
LNK
ACT
LNK
ACT MDI-X
MDI
RS-232 TERMINAL PO RT STATUS
10BASE-T / 100 BASE-TX FAST ETHERN ET SWITCH
PORT ACTIVI TY
10BASE-T / 10 0BASE-TX
RS-232 TERMINAL PO RT STATUS
10BASE-T / 100 BASE-TX FAST ETHERN ET SWITCH
PORT ACTIVI TY
10BASE-T / 10 0BASE-TX
Cable Legend
100 Mbps
100 Mbps (Fiber)
100 m (328 ft)
100 m (328 ft)
AT-LMC100SC
AT-LMC100SC
AT-8224XL
AT-8224XL 2 km (1.2 mi)
