Overview
2
Figure 2 AT-LMC100ST Converter - Front Panel
Figure 3 displays the rear panel of the AT-LMC100 Series Media Converters.
Figure 3 AT-LMC100 Series Converters - Rear Panel
Table 1 lists the maximum operating distances for the media converters.
Table 1 Maximum Operating Distances
Model Type of Connector Maximum Operating Distance
100Base-FX 100Base-TX 100Base-FX 100Base-TX
AT-LMC100SC Multi-mode SC RJ-45 2 km
(1.24 mi) 100 m (328 ft)
AT-LMC100ST Multi-mode ST RJ-45 2 km
(1.24 mi) 100 m (328 ft)
