Figure 18: Example output from the SHOW STP command.

STP Information

------------------------------------------------------------

Name .................. grey

Mode .................. Rapid

RSTP Type ............. Normal

VLAN members .......... vlan4 (4)

Status ................ ON

Number of Ports ....... 2

Number Enabled ...... 2

Number Disabled ..... 0

Bridge Identifier ..... 32768 : 00-00-cd-05-19-28

Bridge Priority ....... 32768

Root Bridge ........... 32768 : 00-00-cd-05-19-28

Designated Bridge ..... 32768 : 00-00-cd-05-19-28

Root Port ............. (n/a)

Root Path Cost ........ 0

Max Age ............... 20

Hello Time ............ 2

Forward Delay ......... 15

Switch Max Age ........ 20

Switch Hello Time ..... 2

Switch Forward Delay .. 15

Transmission Limit .... 3

Name .................. default

Mode .................. Standard

RSTP Type ............. (n/a)

VLAN members .......... default (1)

vlan5 (5)

vlan6 (6)

vlan7 (7)

vlan8 (8)

vlan9 (9)

vlan10 (10)

vlan11 (11)

vlan12 (12)

vlan13 (13)

vlan14 (14)

Status ................ OFF

Number of Ports ....... 22

Number Enabled ...... 0

Number Disabled ..... 22
