Overview
8
Uplink
Figure 4 illustrates multiple AT-FS705L switches can be interconnected using
uplinks from a centralized backbone Fast Ethernet switch.
Figure 4 Uplink Topology
Hub
Hub
Hub
SNMP Station
Sales Department
Engineering Department
Finance Department
IS Department
Fast Ethernet Switch
10 Mbps
100 Mbps
10 Mbps
