Overview
2
Features
❑ LEDs for unit and port status
❑ Auto MDI/MDI-X on the twisted pair ports
❑ Half- or full-duplex operation on both ports
❑ Five RJ-45 twisted pair connectors
❑ Store and forward switching mode
❑ MAC address table with a capacity of 2,000 addresses
❑ Small compact size for use on a desktop or wall-mountable
Status LEDs
Table 1 defines the LEDs for the switch.
Table 1 Status LEDs
LED Color Description
POWER Green Power is applied to the switch.
LINK/ACT Green
Blinking
A valid link has been established on the port.
Data is being received or transmitted on the port.
100M Green
OFF
The port is operating at 100 Mbps.
The port is operating at 10 Mbps.
FDX Green
OFF
The port is operating in full-duplex mode.
The port is operating in half-duplex mode.
