Page 5 of 5

Typical ADSL Router Connections

For Up To 4 Computers













For More Than 4 Computers

To connect more than 4 computers, you can uplink to a Ethernet hub or switch. For
details on how to connect your Ethernet hub or switch, please refer to the
documentation that comes with the Ethernet hub or switch.








ADSL router

ADSL router

Ethernet hub
or switch

The auto MDI/MDI-X feature automatically senses straight and crossover cables.

The auto MDI/MDI-X feature automatically senses straight and crossover cables.

Computers with Ethernet
network cards installed

Computers with Ethernet
network cards installed

To computers with Ethernet
network cards installed
