Chapter 1: Overview
12
Back-to-Back Topology
Figure 10 illustrates two AT-MC103XL media converters in a back-to-
back configuration.
Figure 10. Back-to-Back Topology
LINK TST
M/L ON
4 100Base-FX
LINK
ACT A/N OFF
A/N ON
100Base-TX FDX
LINK
ACT M/L ON
PWR
TX RX
CLASS 1 LASER PRODUCT
AT-MC103XL SINGLE MODE FIBER FAST ETHERNET MEDIA CONVERTER
LINK TST
M/L ON
4 100Base-FX
LINK
ACT A/N OFF
A/N ON
100Base-TX FDX
LINK
ACT M/L ON
PWR
TX RX
CLASS 1 LASER PRODUCT
AT-MC103XL SINGLE MODE FIBER FAST ETHERNET MEDIA CONVERTER
Cable Legend
10 Mbps
100 Mbps
100 Mbps (Fiber)
751
AT-8524M
AT-8524M
AT-MC103XL
AT-MC103XL
