Chapter 1: Overview
18
Front and Back Panels
Figure 1 illustrates the front panel of the AT-GS900/8PS Gigabit Ethernet
Switch.
Figure 1. AT-GS900/8PS Front Panel
The switch back panel is illustrated in Figure 2.
Figure 2. Back Panel
Port
10/100/1000Base-T
Twisted Pair Ports
AT-GS900/8
PoE Limit
LEDs
System
LEDs
PoE
LEDs
1000M
SFP Slot
