Installing the Speakers
This speaker installation guide is for the PSN5040 (BN96-00712A) speakers.
The speakers are sold separately.
14
Parts
How to Assemble the Speakers (when using the stand)
2EA
1EA
1EA
Speakers
1EA
Middle Cabinet
(Wall Mount Only)
Speaker Dust Cover
Speaker Cable
Screw 8EA
Screws
1
Remove the screws indicated on the rear of the PDP (6 screws on the left and right
sides).
