Wall Installation Instructions
1
Do not install the PDP on any location other than a vertical wall.
2
To protect the performance of the PDP and prevent problems, avoid the following locations:
• Do not install next to smoke and fire detectors.
• Do not install in an area subjected to vibration or high voltage.
• Do not install near or around any heating apparatus.
3
Use only recommended parts and components.
10
Installation Notes
Insulation Holder :
4 EA
SCREW! : 4 EA SCREW@ : 12 EA
1EA
2EA
LEFT :1EA
RIGHT :1EA
Parts (Wall attachment panel is sold separately. Check with your dealer)
Wall Mount Bracket
ASSY-HINGE
Support Bars
Screws
