Important
You must disconnect and lock out the electric
supply and the gas supply before any covers or
panels are removed from the machine to allow
access for cleaning, adjusting, installation, or
testing of any equipment per OSHA
(Occupational Safety and Health Administration)
standards.
Please observe all safety precautions displayed
on the equipment and/or specified in the
installation manual included with the dryer.
Dryer must be installed in a location/environment,
which the ambient temperature remains between
40° f (4.44° c) and 130° f (54.44° c).
“Caution: Label all wires prior to disconnection when
servicing controls. Wiring errors can cause improper
operation.”
«Attention: Au moment de l’entretien des
commandes, étiquetez tous les fils avant de les
débrancher. Des erreurs de câblage peuvent entraîner
un fonctionnement inadéquat et dangereux.»
Caution
Dryers should never be left unattended while in
operation.
When discarding or storing your old clothes dryer,
remove the door.
Lorsque vous entreposez ou mettez votre
sécheuse au rebut, enlevez-en la porte.
Do not allow children to play on or in the appliance.
Close supervision of children is necessary when the
appliance is used near children.
Ne laissez pas les enfants jouer dans ou sur l’appareil.
Il est important de surveiller étroitement les enfants
lorsque l’appareil est utilisé non loin d’enfants.
For Your Safety
Do not dry mop heads in the dryer.
Do not use dryer in the presence of dry cleaning
fumes.
Warning
Under no circumstances should the dryer main
door switch, lint drawer switch, or the heat circuit
devices ever be disabled.
The dryer must never be operated with any of
the back guards, outer tops, or service panels
removed. Personal injury or fire could result.
Dryer must never be operated without the lint
filter/screen in place, even if an external lint
collection system is used.
Dryer must not be installed or stored in an area where
it will be exposed to water or weather.
The wiring diagram for the dryer is located behind the
front control panel.
Table of Contents
SAFETY PRECAUTIONS ............................ 2
SPECIFICATIONS ....................................... 3
INSTALLATION PROCEDURES ................. 4
Unpacking/Setting Up ........................................... 4
Location Requirements ........................................ 4
Dryer Enclosure Requirements ........................... 4
Fresh Air Supply Requirements ........................... 5
Exhaust Requirements ........................................ 5
Electrical Information ............................................ 6
Gas Information .................................................... 9
Preparation for Operation/Start-up ..................... 10
Preoperational Tests .......................................... 10
Preoperational Instructions ................................ 10
Shutdown Instructions ........................................ 11
SERVICE/PARTS INFORMATION ............ 12
Service ................................................................. 12
Parts .................................................................... 12
WARRANTY INFORMATION .................... 12
Returning Warranty Cards .................................. 12
Warranty .............................................................. 12
Returning Warranty Parts ................................... 12
ROUTINE MAINTENANCE ....................... 13
DATA LABEL INFORMATION ................... 13
SENSOR ACTIVATED FIRE
EXTINGUISHING (S.A.F.E.) SYSTEM ...... 14
Installation ........................................................... 14
S.A.F.E. System Theory of Operation ................. 16
Disabled S.A.F.E. System ................................... 16
S.A.F.E. Diagnostic Messages ........................... 16
System Reset ..................................................... 16
S.A.F.E. Parts Break Down ................................. 16
