Qc-3 – Alto-Shaam Processing Freezer/Chiller/Refrigeration System QC-3/QC-20/QC-40/QC-50/QC-50 Remote/QC-100/Qc-100 Remote User Manual
Page 8

QUICKCHILLER • INSTALLATION/OPERATION/SERVICE MANUAL • 6.
S U B T I T L E
T I T L E
3"
(76mm)
26-1/2" (673mm)
29-3/4" (756mm)
5-1/4" (133mm)
Electrical Connection
54-3/4" (1391
mm)
14-3/4" (375mm)
34" (864mm)
28" (711mm)
29-3/4" (756mm)
28-1/2" (724mm)
QC-3
PRODUCT\PAN CAPACITY
Approximately 36 lb (16 kg)
MaxiMuM
voluMe
MaxiMuM
: 22-1/2
quarts
(28,5
liters
)
full
-
size
paNs
:
gastroNorM
1/1:
Three (3) 20" x 12" x 2-1/2"
(530 x 325 x 65mm)
capacity
for
up
to
three
(3)
optioNal
staiNless
steel
wire
shelves
REFRIGERATION
R404a Refrigerant
One (1) 3/4 hp Condensing Unit:
3,810 BTU's per hour at -5°F (-21°C) in the freeze mode
7,260 BTU's per hour at +20°F (-7°C) in the chill mode
I N S T A L L A T I O N
S I T E I N S T A L L A T I O N
WEIGHT
net
: 350 lb (159 kg)
ship
: 405 lb (184 kg)
carton
dimensions
:
(
l
x
w
x
h
)
40"
x
34"
x
43"
(1016mm x 864mm x 1092mm)
