1_ connections
connections
1
Using Video/Audio cables, connect the VIdeO (yellow)/AUdIO
(red and white) OUt jacks on the rear of the DVD player to the
VIdeO (yellow)/AUdIO (red and white) In jacks of your TV.
Turn on your DVD player and TV.
note
- noise may be generated if the audio cable placed too close to the power cable.
- If you want to connect to an Amplifier, please refer to the Amplifier connection page. (See pages 17 to 18)
- The number and position of the jacks may vary depending on your TV set. Please refer to the user's manual
of your TV.
- If there is one audio input terminal on the TV, connect it to the [AUDIO OUT][left] (white) jack of the DVD
player.
red
WHIte
YeLLOW
red
WHIte
YeLLOW
Audio Cable
(Included)
Video Cable
(Included)
Press the input selector button on your TV remote control until
the Video signal from the DVD player appears on the TV
screen.
Connecting to a tV (Video)
