1 PC IN [PC] / [AUDIO]
Connects to the video and audio output jacks on your PC.
2 AV IN , 2
Video and audio inputs for external devices, such as a camcorder or VCR.
S-VIDEO
Connects an S-Video signal from a camcorder or VCR.
3 hDMI IN , 2, 3 / DVI IN(hDMI2)[R-AUDIO-L]
Connects to the HDMI jack of a device with an HDMI output.
- No sound connection is needed for an HDMI to HDMI connection.
Use the HDMI IN 2 jack for DVI connection to an external device. Use a DVI to HDMI cable or DVI-HDMI adapter (DVI to
HDMI) for video connection and the DVI IN (HDMI2) [R-AUDIO-L] jacks for audio.
- When using an HDMI/DVI cable connection, you must use the HDMI IN 2 jack.
4 ANt IN
Connects to an antenna or cable TV system.
5 SERVICE
- Connector for SERVICE only.
- Connect this to the jack on the optional wall mount bracket. This will allow you to adjust the TV viewing angle using your
remote control.
6 (hEADPhONE)
Connects a set of external headphones for private listening.
7 AUDIO OUt
Connects to the audio input jacks on your Amplifier/Home theater.
8 POWER INPUt
Connects the supplied power cord.
9 COMPONENt IN , 2
Connects Component video/audio.
0 KENSINGtON LOCK(depending on the model)
The Kensington lock (optional) is a device used to physically fix the system when used in a public place. If you want to use a
locking device, contact the dealer where you purchased the TV.
The location of the kensington lock may be different depending on its model. ➣
English - 5
