To avoid risk of electrical shock, personal injury, or
death, disconnect power to unit before servicing.

Disassembly Procedures

RS3100007 Rev. 0

28

WARNING

!

Weldment and Bearing Assembly

1. Remove outer tub, see Outer Tub” procedure,

steps 1 through 11.

2. Remove screw, washer and helix holding drive pulley

to input shaft and transmission assembly.

3. Lift drive pulley up and off input shaft of transmission

assembly.

NOTE: When reinstalling pulley, place a small amount

of No. 03200P Lubricant on top side of the drive
pulley that will be contacting large flat washers.
Lubricate helix ramps and bore with a small
amount of No. 03200P Lubricant.

DO NOT OVER LUBRICATE! Excess lubricant

can be thrown into pivot dome area during
normal washer operation. Any lubricant on pivot
dome, hose or friction ring will affect washer
operation. This condition will persist until
lubricant is removed.

4. Remove bolts securing brake pads and brake

assembly to weldment assembly. Remove brake
assembly and pads off bottom of weldment
assembly.

NOTE: When reinstalling brake assembly, replace all

three brake pads. DO NOT replace worn pads
only. Apply a small amount of No. 265494P
Silicone Lubricant to both sides of each brake
pad where it will contact brake assembly.

DO NOT OVER LUBRICATE! Excess lubricant

can be thrown into pivot dome area during
normal washer operation. Any lubricant on pivot
dome, base or friction ring will offset washer
operation. This condition will persist until
lubricant is removed.

5. After brake is installed, put washer through the

following check to verify brake is operating properly.

a. Turn off electrical power to washer.
b. Turn drive pulley one complete revolution in

agitation direction, then push drive pulley up
against brake.

c. Check for a .030 (.76 mm) minimum gap between

drive pulley and helix ramp surfaces.

NOTE: If gap is less than .030 (.76 mm), brake may not

stop washtub from spinning in required seven
seconds because brake will not close properly.

d. Turn on electrical power to washer and start

washer in the final spin.

NOTE: After installing complete tub module in washer

and all hoses have been reconnected, add at
least a quart of water to washtub to lubricate
pump seals. Running a pump without water will
ruin the seals.

After washtub has been spinning for two

minutes, normal spin speed should be
427 ± 25 RPM SLOW speed and 640 ± 25 RPM
FAST speed on one and two speed models; or
473 ± 25 RPM on SLOW speed and
710 ± 25 RPM on FAST speed on some two
speed models and all three speed models.
Three speed models never spin on the lowest
speeds. If not, the cause could be dragging
brake pads. If problems occur with steps (c) or
(d), remove brake assembly and correct
problem.

6. Remove bolts securing counterweight and each

support leg to outer tub. Lift transmission, weldment
assembly and counterweight off tub.

NOTE: It may be necessary to tap lightly on the

weldment assembly to loosen it from
transmission tube.

Torque screws between 100 to 150 inch-

pounds.

7. Remove screws and washers securing

counterweight to leg on weldment assembly.

8. Reverse procedure to reassemble.
