20

Specifications

MAIN UNIT CX-LFA500

TUNER

FM tuning range

87.5 MHz to 108 MHz

FM usable sensitivity (IHF)

16.8 dBf

FM antenna terminal

75

Ω (unbalanced)

AM tuning range

531 kHz to 1602 kHz

AM usable sensitivity

350 µV/m

AM antenna

Loop antenna

AMPLIFIER

Power output

Rated: 16 W + 16 W(6 ohms, T.H.D.
1 %, 1 kHz/DIN 45500)
Reference: 20 W + 20 W(6 ohms,
T.H.D. 10 %, 1 kHz/DIN 45324)
MUSIC POWER
40 W + 40 W

Input

AUX IN: 500 mV

Outputs

SPEAKERS: 6 ohms or more
PHONES: 32 ohms or more

CASSETTE DECK

Track format

4 tracks, 2 channels stereo

Frequency response

50 Hz – 10000 Hz

Recording system

AC bias

Heads

Recording/playback

× 1, erase × 1

CD PLAYER

Laser

Semiconductor laser (

λ = 780 nm)

Emission duration: continuous

D/A converter

1 bit dual

Signal-to-noise ratio

80 dB (1 kHz, 0 dB)

Wow and flutter

Unmeasurable

SPEAKER SYSTEM SX-LFA500

Speakers system

2 way, bass-reflex type (magnetic
shielded)

Speaker units

Woofer: 120 mm cone type
Tweeter: 30 mm balance dome type

Nominal impedance

6

Dimensions (w/h/d)

Approx. 155

Ч 250 Ч 218 mm

Mass

Approx. 2.3 kg net per speaker

GENERAL

Power requirements

230 V AC, 50 Hz

Power consumption

52 W

Power consumption in standby mode

with ECO mode on: 0.3 W
with ECO mode off: 10 W

Dimensions (w/h/d)

Approx. 190

Ч 250 Ч 284 mm

Mass

Approx. 3.7 kg

Supplied accessories:

FM antenna (1)
AM antenna (1)
Speaker cords (2)
Remote commander (1)
Batteries (2)

Specifications and external appearance are subject to change
without notice.

COPYRIGHT
Check copyright laws relevant to recordings from discs, radio
or tape for the country where the unit is to be used.
