Image Tab Definition
Adjusts the Position, Size and Rotation values.
Geometry 1
Rotation Size Position
Geometry 2
Pincushion Pinbalance Trapezoid Parallelogram
Other
Moire
Degauss
Sidepin Corner Top
Sidepin Corner Bottom
Pinbalance Corner Top
Pinbalance Corner Bottom
Geometry 1
Adjusts the Position, Size and Rotation values.
z
Position
z
Size
z
Rotation
Geometry 2
Adjusts the Pincushion, Pinbalance, Trapezoid and Parallelogram
values.
z
Pincushion
z
Pinbalance
z
Trapezoid
z
Parallelogram
Other
Adjusts the Moire, Degauss, Sidepin Corner, and Pinbalance
Corner values.
z
Moire
z
Degauss
z
Sidepin Corner Top
z
Sidepin Corner Bottom
