AXIS 2460 User’s Manual
Recording Storage and Reduction
51
The recording mode will apply to the whole system and is selected on the Recording
Options Overview page in the administration tools. The following diagrams provide a
graphical overview of how a recording (identical in all three cases) will be reduced and
stored by the different recording modes.
While Normal mode has kept the frame rate at 100% the whole time, the other modes have
reduced the recording. Extended mode has reduced the frame rate at roughly equal
intervals, and saved the recording for roughly twice as long. Extended Long mode has
quickly reduced the recording to a much lower frame rate, which is then maintained for
much longer.
Time x
Frame rate
100 %
0 %
50 %
Time 2x
Frame rate
100 %
0 %
50 %
Time 5.25x
Frame rate
100 %
0 %
50 %
Extended Mode
Normal
Mode
Extended Long Mode
