AXIS 2460 User’s Manual
Setting up Events and Alarms
27
Send an email to [email address] when this event occurs
Send email -
Check this box to send an e-mail to the specified recipient whenever this event
occurs.
Include Image -
Checking this box will attach to the e-mail an image from each of the
cameras used by the event.
Note:
If you see the text
(No Mail Recipient is Specified)
, an address must be entered on
the e-mail Settings page. Click the E-mail Settings button to go directly to that
page.
Complete Alarm Settings
This section describes how to configure alarms for the four inputs and one output. Note
that this describes the configuration of the physical alarm devices connected to the
Network DVR. These settings will also influence the behaviour of the alarm LEDs on the
front panel.
Input Settings
The following settings can be configured for each input:
Enabled -
Check to enable the input. This must always be done if you want the various
events to be able to use the input.
Input Name -
Used wherever the input is shown. Use a descriptive name.
Generated When Circuit is... -
Select Open (Falling) or Closed (Rising). The correct setting will
depend on the actual device used, and whether it generates an alarm when the circuit
closes or when it opens. This setting does not determine if the alarm input is enabled or
not, but simply how it functions. Nor does the setting have anything to do with the settings
for Active/Inactive on the event settings page.
Output Relay Settings
When the output relay is enabled on this page it will then be available to all events, which
in turn can have the relay enabled or disabled, independently of each other. The settings
available are Enabled and Output Name, as described above for inputs.
After making these settings, click Save.
