Installation
3. Brouter Administration
1. Login/Password Administration
4. Maintenance...
5. Port Status/Control
6. Exit
This line is used to provide abbreviated help on the currently selected field.
ENTER
Main Menu
2. TCP/IP Administration...
EXIT REFRESH
Release 1.0, Issue x.y
HELP
Screen 2-4. Main Menu
5. Select Maintenance and then Set System Time and Date . Follow the
instructions for the Set System Time and Date screen in Chapter 3.
Task 11B: Assign the DEFINITY LAN Gateway
Machine ID (optional)
This subtask is only necessary if the customer is attaching the DEFINITY LAN
Gateway system to an existing TCP/IP LAN.
NOTE:
AT&T support services for the DEFINITY LAN Gateway system will not
troubleshoot a customer LAN. If the customer LAN is experiencing
difficulties, customers should follow the escalation path supplied by their
LAN provider.
1. Make sure the DEFINITY LAN Gateway Main Menu is displayed. (See
Task 11A.) Select TCP/IP Administration and then This Host. The
following screen appears:
Issue 1 January 1996 2-33
