Installation
change circuit-packs 1 Page 1 of 5
------------------------------------------------------------------------
CARRIER 1A
Slot Code Name Slot Code Name
01: _____ 11: _____
02: _____ 12: _____
03: LGATE RESERVED LGATE 13: _____
04: LGATE RESERVED LGATE 14: _____
05: LGATE RESERVED LGATE
06: TN2208 LAN GATE BOARD * Use slots A01-A14 with
07: LGATE RESERVED LGATE * J58890G-1 control carrier.
08: _____ * Use slots A01-A10 with J58890L-1
09: _____ * or J58890M-1 control cabinet.
10: _____ * Use slots A01-A09 with J58890AH
’#’ indicates circuit pack conflict * or J58890AJ control carrier.
Screen 2-1. Change Circuit-Packs
2. Use the list config command for a hardware system configuration report
such as the one shown below. This report shows the Multi-Function Board
(TN2208 circuit pack) when you enter either
list configuration all,
port-network, carrier, or board (station) commands.
list configuration all
Page 1
------------------------------------------------------------------------
SYSTEM CONFIGURATION
Board
Number Board Type Code Vintage Assigned Ports
1A01 EXPANSION INTF TN776 000001
1A02 EXPANSION INTF TN776 000001
1A03 RESERVED LGATE TN2208 lgate u u u u u u u u
1A04 RESERVED LGATE TN2208 lgate u u u u u u u u
1A05 RESERVED LGATE TN2208 lgate u u u u u u u u
1A06 LAN GATE BOARD TN2208 000001 01 u u u u u u u
u u u u u u u u
u u u u u u u u
1A07 RESERVED LGATE TN2208 lgate u u u u u u u u
Screen 2-2. List Configuration
2-30 Issue 1 January 1996
