RAWS-H Remote Automated Weather Station
TABLE 4-6. FM/FT Connector (color coded brown)
Connector Pin Description CR1000 Terminal
A CS205 Temperature Signal 4L
B Sensor Ground
C CS205 Temperature Excitation VX1
D CS506 FM Enable C8
E CS506 FM Signal 4H
F CS506 FM 12 V 12V
4.6 Barometric Pressure
The barometric pressure sensor (pn CS100-QD) is mounted inside the RAWS
environmental enclosure and the sensor wires are attached to the CR1000
printed circuit board wiring panel.
TABLE 4-7. CS100-QD Wiring
CS100 Wire Color CR1000 Terminal
Blue 5L
Yellow
Red 12V
Clear G
Black G
Green C4
The CS100 is sensitive to static when the back plate is
removed. To avoid damage, take adequate anti-static
measures when handling this sensor. CAUTION
5. Equipment Wiring and Troubleshooting
5.1 Solar Panels
5.1.1 General Description
The RAWS solar panel is a photovoltaic power source used for charging lead
acid batteries. The SP20-Handar 20 watt solar panel is used for system
configurations that have higher-than-average power requirements. It is also
recommended for use at higher elevations and latitudes. The solar panel
should be mounted facing the equator.
