RAWS-H Remote Automated Weather Station

4.4 Wind Speed and Direction

The wind set attaches to the connector labeled WS/WD; this connector is color
coded red. The wind set is internally wired from the RAWS connector panel to
the CR1000 datalogger.

TABLE 4-4. WS/WD Connector (color coded red)

Connector Pin Description

CR1000 Terminal

A Sensor

Ground

B

Wind Direction Excitation VX2

C Wind

Direction

Signal

2H

D

Power Ground

G

E

+12 V power

12V

F

Wind Speed Signal

P1

4.4.1 SDI-12 Sensor

An SDI-12 sensor can be attached to the connector labeled SDI-12; this
connector is color coded yellow. The SDI-12 sensor is internally wired from
the RAWS connector panel to the CR1000 datalogger.

TABLE 4-5. SDI-12 Connector (color coded yellow)

Connector Pin Description

Datalogger Connection

A SDI-12

Signal

C7

B

12 V

12V

C Power

Ground

G

4.5 Fuel Moisture and Fuel Temperature

The Campbell Scientific CS506 and CS205 sensors are combined into one
connector (pn CS516-LQ). This sensor is internally wired from the RAWS
connector panel to the CR1000 datalogger. This sensor attaches to the
connector labeled FM/FT, which is color coded brown.
