RAWS-H Remote Automated Weather Station


TABLE 4-1. TEMP/RH Connector (color coded orange)

Connector Pin

Description

CR1000 Terminal

A Temperature

H

1L

B

Sensor Excitation

VX1

C Sensor

Signal

L/

D

Power Ground

G

E

RH Signal

1H

F

Switched 12 V

SW_12V

4.2 Rain Gage

The rain gage attaches to the connector labeled PRECIP; this connector is color
coded blue. This sensor is internally wired from the RAWS connector panel to
the CR1000 datalogger.

TABLE 4-2. PRECIP Connector (color coded blue)

Connector Pin Description

Datalogger Connection

A Tipping

Bucket

C6

B 5

V

5V

C Ground

G

4.3 Solar Radiation

The solar radiation sensor attaches to the connector labeled SOLAR RAD
SDI-12; this connector is color coded green. The pyranometer sensor is
internally wired from the RAWS connector panel to the CR1000 datalogger.

TABLE 4-3. SOLAR RAD SDI-12 Connector (color coded green)

Connector Pin

Description

CR1000 Terminal

A

Solar Sensor +

3H

B

Solar Sensor -

3L shorted to

C Solar

Sensor

Ground

D

SDI-12 Ground

G (used for a second SDI-12 sensor)

E

SDI-12 Signal

C5 (used for a second SDI-12
sensor)

F

SDI-12 12 V

12V (used for a second SDI-12
sensor)
