Raven110 GPRS/EDGE AirLink Cellular Modem
PN 18285 1 dBd Omni Directional Antenna
PN 14454 9dBd Directional Yaggi Antenna
PN 14453 Half-Wave Dipole Whip Antenna
FIGURE 4.2-2. Antennas for Use with the Raven Modems
• Power Supply (see power considerations).
• Environmental Enclosure— ENC 10/12, ENC 12/14, or ENC 16/18.
4.3 Power Considerations
• A power cable included with the modem connects to the datalogger's 12 V
or switched 12 V terminal. Connection to the switched 12 V terminal
allows the datalogger to switch power to the modem during scheduled
transmission intervals if desired.
• When using the switched 12 V terminal, the modem can typically be
powered with a BP12 battery, CH100 charger/regulator, and MSX10 solar
panel.
