PConnect for the Palm Handheld
device, others have dip switches on the outside or are configured by issuing
commands using a terminal emulation program. Refer to the adapter
manufacturer’s information for instructions on configuration.
The interface and/or cables that are used to connect the adapter to the
datalogger will vary, depending upon whether the device acts like a DTE
(computer) device or DCE (PDA) device. In some instances, this is evident by
the pin-out of the adapter, but not always. A general rule is if the adapter has a
9 pin female connector, then the adapter is connected to the datalogger using
the PDA to CS I/O connector for the CS I/O port or the PDA to RS232 cable
for the RS232 port. If the adapter has a 9 pin male connector, then the adapter
is connected to the datalogger using an SC32B for the CS I/O port or it can be
connected directly to the RS232 port.
Note that Bluetooth to serial adapters require a power source, typically
between 5 and 12 volts. This power can be supplied from the datalogger’s
wiring panel, from the adapter’s rechargeable battery if available, or from
another external supply. If the power is provided from the datalogger’s wiring
panel, this additional power consumption must be taken into account when
calculating the overall power budget for the site.
4. Using the PConnect Software
4.1 Configuring Stations
Start the PConnect software on the Palm handheld. The first time you run the
PConnect software, an opening screen will appear. Tap OK to clear the
Welcome message. As indicated by the Welcome message, set up your first
station by pressing New. A list of dataloggers will appear on the screen:
7
