CS10-L and CS15-L Current Transformers
2: Burst Measurement (P23)
1: 1 Input Channels per Scan
2: 15 2500 mV Fast Range
3: 1 In Chan
4: 0001 Trig/Trig/Dest/Meas Options
5: 2.0 Time per Scan (msec)
6: .05 Scans (in thousands)
7: 0 Samples before Trigger
8: 0.0 mV Limit
9: 0000 mV Excitation
10: 71 Loc [ Amps_1 ]
11: .2 Multiplier
12: 0.0 Offset
3: Burst Measurement (P23)
1: 1 Input Channels per Scan
2: 15 2500 mV Fast Range
3: 2 In Chan
4: 0001 Trig/Trig/Dest/Meas Options
5: 2.0 Time per Scan (msec)
6: .05 Scans (in thousands)
7: 0 Samples before Trigger
8: 0.0 mV Limit
9: 0000 mV Excitation
10: 123 Loc [ AmpsII_1 ]
11: .2 Multiplier
12: 0.0 Offset
4: End (P95)
5: Beginning of Subroutine (P85)
1: 2
Subroutine 2
6: Z=F x 10^n (P30)
1: 0.0 F
2: 00 n, Exponent of 10
3: 1 Z Loc [ Counter ]
7: Beginning of Loop (P87)
1: 0 Delay
2: 50 Loop Count
8: Z=Z+1 (P32)
1: 1 Z Loc [ Counter ]
9: If (X<=>F) (P89)
1: 1 X Loc [ Counter ]
2: 1 =
3: 50 F
4: 10 Set Output Flag High (Flag 0)
10: Set Active Storage Area (P80)
1: 3 Input Storage Area
2: 2 Loc [ BurstAmps ]
13
