CS10-L and CS15-L Current Transformers

8: Step Loop Index (P90)

1: 2

Step


9: Z=X (P31)

1: 2

X Loc [ BurstAmps ]

2: 4

-- Z Loc [ CS10_1 ]


10: Do (P86)

1: 3

Call

Subroutine

3


11: Z=X (P31)

1: 3

X Loc [ Burst_A2 ]

2: 5

-- Z Loc [ CS10_2 ]


12: End (P95)

13: Do (P86)
1: 51

Set Port 1 Low


; This part of the program will store a one minute average of the amperage.

14: If time is (P92)
1: 0

Minutes (Seconds --) into a

2: 1

Interval (same units as above)

3: 10

Set Output Flag High (Flag 0)


15: Set Active Storage Area (P80)^17815
1: 1

Final Storage Area 1

2: 60

Array

ID


16: Real Time (P77)^10331
1: 1220

Year,Day,Hour/Minute (midnight = 2400)


17: Average (P71)^5143
1: 64

Reps

2: 4

Loc [ CS10_1 ]


*Table 2 Program
02: 0.0000 Execution

Interval

(seconds)


*Table 3 Subroutines
;
; Parameter 2 should be 2500 mV for 50-200 amps
; should be 250 mV for 5-49 amps
; should be 25 mV for 0-4.9 amps
; Parameter 5 should be 2.0 msec for 50 Hz or 60 Hz
; Parameter 6 should be 0.05 thousand scans for 50 Hz or 60 Hz
; if parameter 5 & 6 are 2.0 and 0.05, then you have 5 complete cycles at 50 Hz
; or 6 complete cycles at 60 Hz.

1: Beginning of Subroutine (P85)
1: 1

Subroutine

1
