CS10-L and CS15-L Current Transformers
5.5 CR1000 with Multiplexer Sample Program
This program uses the CR1000 and an AM16/32-series multiplexer to read 32
CS10-L current transformers.
'CR1000 program to measure rms current
PipeLineMode
'must be pipeline mode
Const num_samples = 100 '6 waveforms for 60 Hz, 5 waveforms for 50 Hz
Const NumSensors=32 'Number of Sensors on the Mux MUX in 2X32 Mode *****
'Sensor wired to Low on each of the 32 channels.
'Odd Low on Mux wired to SE2 on Datalogger
Public Amps(NumSensors), i, Batt_Volt 'the line current
Public Amp_mult, TempAmps
Dim i_sig (num_samples)
'to hold the burst measurements, each 100 samples long
PreserveVariables 'to store values between power cycles
DataTable (AmpTable,True,-1)
DataInterval
(0,1,Min,10)
Maximum (NumSensors,Amps,IEEE4,False,False)
Average (NumSensors,Amps,FP2,False)
EndTable
BeginProg
Amp_mult = 0.2 '0.2 multiplier for the CS10-L/CS15-L
Scan (10,Sec,0,0)
Battery (Batt_volt)
'Turn AM16/32 Multiplexor On
PortSet(4,1)
i=0
SubScan(0,uSec,NumSensors)
'Switch to next AM16/32 Multiplexer Channel
PulsePort(5,10000)
i=i+1
VoltSe (i_sig (1), num_samples, mV2500,-2, True, 1000, 0, 1.0, 0)
StdDevSpa (Amps(i), num_samples, i_sig (1))
Amps(i) = Amps(i) * Amp_mult 'put in amps
If Amps(i) <= 0.15 Then Amps(i) = 0
NextSubScan
'Turn AM16/32 Multiplexer Off
PortSet(4,0)
CallTable
(AmpTable)
NextScan
EndProg
