15. enclosure with the –lm bracket, N figure 6-15b, Figure 6-15c – Campbell Scientific CM110, CM115, CM120 Tripod Installation User Manual

Page 28: Figure 6-15)

background image

Tripod Installation Manual Models CM110, CM115, CM120

A

B

C

FIGURE 6-15. Enclosure with the –LM bracket

Keyhole Notch

Phillips Head Screw

U-bolt Bracket

–LM Bracket

20
