Tripod Installation Manual Models CM110, CM115, CM120

5. Specifications

CM110

CM115

CM120

Height w/mast insert:

3 m (10 ft)

4.7 m (15.5 ft)

6.4 m (21.0 ft)

Weight:

15 kg (34 lb)

18 kg (40 lb)

21 kg (46 lb)

Base diameter w/legs extended: 2 m (7 ft)

2 m (7 ft)

Dimensions of collapsed tripod: 15 x 15 x 145 cm

(6 x 6 x 57 in)

15 x 15 x 145 cm

(6 x 6 x 57 in)

15 x 15 x 145 cm

(6 x 6 x 57 in)

Vertical load limit:

45 kg (100 lb)

Mast description

Number of sections:

Length:

1.4 m (4.6 ft)

2.8 m (9.3 ft)

4.3 m (14.0 ft)

Length w/insert:

2.6 m (8.6 ft)

4.1 m (13.3 ft)

5.5 m (18.0 ft)

OD:

4.8 cm (1.9 in)

Insert OD:

4.45 cm (1.75 in)

Mounting hole in tripod foot:

0.75 in diameter hole

for user-supplied

0.5 in J-bolts

0.75 in diameter hole

for user-supplied

0.5 in J-bolts

0.75 in diameter hole

for user-supplied

0.5 in J-bolts

Wind load recommendations

Sustained wind (mph):

*75 (unguyed)

80 (guyed at feet)

*56.25 (guyed at feet)

75 (guyed at 60°)

*42.25 (guyed at feet)

65 (guyed at 60°)

Gust tolerance (mph):

95 (unguyed)

100 (guyed at feet)

71.25 (guyed at feet)

95 (guyed at 60°)

55.25 (guyed at feet)

85 (guyed at 60°)

Tote bag dimensions:

20 cm (8 in) diameter,

152 cm (60 in) length

20 cm (8 in) diameter,

152 cm (60 in) length

20 cm (8 in) diameter,

152 cm (60 in) length
