Tripod Installation Manual Models CM110, CM115, CM120

FIGURE 6-12. Lightning rod and tripod ground lug

Ground Lug

Ground Wire

Enclosure Ground Lug

Enclosure Ground Wire

Ground Lug

Clamp

Lightning Rod
