CM106K Tripod
4. Specifications
Measurement Height: 10 ft (3.0 m)
Vertical Load Limit: 100 lb (45 kg)
Mast Outer Diameter: 1.90 in. (48 mm)
Base Diameter:
11 ft (3.4 m)
Leveling Adjustment: Clamp brackets on each leg, adjust individually
Leg Base: 6 in. by 3.5 in. with one 0.84 in. hole for stakes
(150 x 89 mm with one 21 mm hole for stakes)
Portability: Collapsible to 9 in. diameter by 100 in (230
mm x 2.54 m) length
Weight with Mast: 67 lb (30 kg)
Allowable Wind Speeds*
Tripod Configuration Sustained Wind Wind Gust
Unguyed 80 mph (36 m/s) 104 mph (46 m/s)
Guyed 115 mph (51 m/s) 150 mph (67 m/s)
*Allowable wind speed values assume:
• Mast and leg components are made of steel (minimum yield
strength of 36 ksi[248 MPa])and fabricated according to the
specified design
• 14 x 16 in. enclosure at mast base
• 10.5 x 16.5 in. solar panel at mast base
• Crossarm and sensors (1.4 ft 2 projected area) at mast top
• Adequate ground anchors (stakes can pull out at lower wind
speeds)
5. Tools List (for tripod, mast, enclosures, and
crossarms)
1/2” and 7/16” open end wrenches
adjustable wrench
Phillips head screw drivers (medium, small)
Straight bit screwdrivers (large, medium)
12” torpedo level
side-cut pliers
pencil
tape measure
compass and site declination angle
shovel
sledge hammer (for driving ground rod and stakes)
step ladder
