Page 28
CM106B Tripod
6.2.3 CM220 Right Angle Mounting Kit
The CM220 attaches a vertical pipe (1.0-in. to 1.5-in. OD) to the CM200-series
crossarms or horizontal pipe (1.0-in. to 1.5-in. OD) as shown in FIGURE 6-15.
FIGURE 6-15. CM220 Right Angle Mounting Kit
CM220
CM220
20
