43347 RTD Temperature Probe, 43502 and 41003-5 Radiation Shields

The 43347-IX is measured with the Resistance measurement instruction with
the CR3000 and CR5000 dataloggers. The Resistance measurement applies a
switched current excitation and measures the voltage across the 1000 ohm
RTD. The result, with a multiplier of 1 and an offset of 0, is the RTD
resistance in ohms. The measurement result is converted to temperature with
the PRT instruction for uncalibrated probes, or with a polynomial equation for
calibrated probes. Calibrated probes include a calibration certificate with the
polynomial coefficients.

The Resistance and PRT Instructions with their parameters are listed below:

Resistance(Dest, Reps, Range, DiffChan, IexChan, MeasPEx, EXuA, RevEx,
RevDiff, SettlingTime, Integ, Mult, Offset)

PRT(Dest, Reps, Source, Mult, Offset)

TABLE 6-2 shows the sensor wiring for the measurement examples.

TABLE 6-2. Wiring for Measurement Examples

Color Function

CR3000,

CR5000

Red

Switched Current Excitation

IX1

White Differential

High

1H

Green Differential

Low

1L

Black Excitation

Return

IXR

Clear Shield

43502 Shield

White Tachometer

Red *12V

power

Black *Gound

*wired to the 115 Vac/12 DC transformer supplied with the 43502,
or separate 12 Vdc supply

6.2.1 Datalogger Programming for Calibrated 43347–IX Probes

Calibrated 43347-IX probes are provided with a calibration certificate that
gives the relationship of resistance to temperature as Equation “T”, as shown in
the example below:

T = -250.052585 + R x 2.375187E-1 + R

2

x 1.258482E-5

The measurement result of the Resistance instruction (ohms) is converted to
temperature with a polynomial equation and the coefficients from equation
“T”, as shown below.

The following example program measures a calibrated 43347-IX probe every 1
second and stores a 15 minute average temperature in degrees Celsius.
