43347 RTD Temperature Probe, 43502 and 41003-5 Radiation Shields

TABLE 5-1. Wiring for Measurement Examples


Color


Function

Datalogger Channels used for
Measurement Examples

Clear Shield

(G) for CR10(X)

Red Switched

Excitation

E1

White Differential

High 2H

Green Differential

Low 2L

Black Differential

High 1H

Orange Differential

Low

1L

Purple Analog

Reference

(AG) for CR10(X)

43502 Shield

White

Tachometer

C1, C6 for CR10X

Red *12V

Power

Black Ground

*wired to the 115 Vac/12 DC transformer supplied with the
43502, or separate 12 Vdc supply

5.1 Programming for Calibrated 43347-VX Probes

Calibrated 43347 probes are provided with a calibration certificate from R.M.
Young Co. that gives the relationship of resistance to temperature (°C) as
Equation “T”.

T = -250.052585 + R x 2.375187E-1 + R

2

x 1.258482E-5

The measurement result of the instruction with a multiplier of 1.0 and an offset
of 0.0 is R

s

/R

f

= the RTD resistance divided by 1000.

5.1.1 CR1000 Example for Calibrated 43347-VX Probes

Because the calibration coefficients are to convert sensor resistance (Rs) to
temperature, the BrHalf4W measurement result (Rs/Rf) must be multiplied by
1000 (Rf), before the coefficients are applied.

'CR1000

'Declare Variables and Units
Public RTD_Res

Public RTD_Cal_C
Units RTD_Cal_C = Deg C

Public 43502_Tach
Units 43502_Tach = Hz
