Ba c, Ab b – Campbell Scientific 21108 RF450 Demo Kit User Manual
Page 6
21108 RF450 Demo Kit
b
a
c
FIGURE 1-2. The middle layer contains two (a) 14221 Omnidirectional antennas; two (b) COAX-SMA
antenna cables; and two (c) COAX-NTN antenna cables with surge suppressors attached.
a
a
b
b
FIGURE 1-3. The bottom layer contains two (a) 14201 Yagi antennas and two (b) 20644
Omnidirectional antennas w/adhesive mount.
2
