21108 RF450 Demo Kit

SN:

CS I/O

CTS

TX

CD

RF450

1 W

att

Spread Spectrum

SLA

VE

FIGURE 4-1. The Slave Radio

TABLE 4-1. LED Description

Connection Quality CTS LED

CD LED

Excellent

solid red

solid green

Good

blinks red frequently

solid green

Poor

blinks red infrequently solid green

None

blinks red frequently

solid red

5. Returning the Equipment

Pack the equipment in the boxes the equipment originally came in (see Figures
5-1 through 5-3). Use the Component Checklist to ensure that the boxes
contain all of equipment that was originally shipped.

It is the responsibility of the customer to ensure that all
components of the kit are returned to Campbell Scientific.
Customers will be charged for lost or damaged
components.

CAUTION

6
