21108 RF450 Demo Kit
This RF450 Demo Kit can be rented for two weeks. The kit can help you
determine the best antenna options for your system and ensure that the radios
will work in your system's environment.
The rental time period starts when Campbell Scientific ships the
NOTE
Demo Kit and ends when Campbell Scientific receives the kit. A
weekly rental rate will be charged for kits that are returned late.
1. Unpack Equipment
Verify that you have all of the equipment (see the enclosed Component
Checklist and Figures 1-1 through 1-3). After unpacking, save the box, foam,
and Component Checklist. They will be required for shipping the kit back to
Campbell Scientific.
Contact Campbell Scientific if any of the equipment is missing.
NOTE
a
a
b
d
b
c
FIGURE 1-1. Top layer of the box contains two (a) plastic enclosures housing the RF450 radio and
PS100 Power Supply; two (b) 15966 wall chargers; two (c) 19512 whip antennas; (d) box holding
antenna mounting brackets; and diagnostic CD (sits next to (d)).
1
