R.M. Young Wind Sentry
'Call Data Tables and Store Data
CallTable(Table1)
NextScan
EndProg
5.4.2 CR10X Example Program
;{CR10X}
*Table 1 Program
01: 5.0000 Execution
Interval (seconds)
1: Batt Voltage (P10)
1: 1
Loc [ Batt_Volt ]
;03001 or 03101 RM Young Wind Sentry Wind Speed Sensor measurement - WS_ms:
2: Pulse (P3)
1: 1
Reps
2: 1 Pulse Channel 1
3: 21 Low Level AC, Output Hz
4: 2 Loc [ WS_ms ]
5: 0.75 Multiplier
6: 0.2 Offset
3: If (X<=>F) (P89)
1: 2
X Loc [ WS_ms ]
2: 4 <
3: 0.21 F
4: 30 Then Do
4: Z=F x 10^n (P30)
1: 0 F
2: 0 n, Exponent of 10
3: 2 Z Loc [ WS_ms ]
5: End (P95)
;03001 or 03301 RM Young Wind Direction Sensor measurement - WindDir:
6: Excite-Delay (SE) (P4)
1: 1
Reps
2: 5 2500 mV Slow Range ;5000 mV(slow/60hz) range for CR23X, 21X, or CR7
3: 1 SE Channel
4: 1 Excite all reps w/Exchan 1
5: 2 Delay (0.01 sec units)
6: 2500 mV Excitation ;5000 mV for CR23X, 21X, or CR7
7: 3 Loc [ WindDir ]
8: 0.142 Multiplier ;0.071 for CR23X, 21X, or CR7
9: 0 Offset
