Met One 014A Wind Speed Sensor

7.3 Wiring

The 014A is typically connected to a datalogger’s pulse port (see TABLE 7-1).

TABLE 7-1. Connections to Campbell Scientific Dataloggers

Pulse Channels

Color

Wire Label

CR800

CR850

CR5000

CR3000

CR1000

CR9000X

CR510

CR500

CR10(X)

21X

CR7

CR23X

CR200(X)

Black Signal

Pulse

Pulse

Pulse

P_SW

White Signal Reference

G

Clear Shield

G

A control port may also be used to measure the 014A. With this option, the

white wire is connected to the 5 V terminal. Please note that the control port

method cannot be used with a CR200(X), CR500, CR510, CR7, 21X, or CR10

datalogger.

TABLE 7-2. Connections to Campbell Scientific Dataloggers

Control Ports

Color

Wire Label

CR800

CR850

CR5000

CR3000

CR1000

CR9000X

CR10X

CR23X

Black Signal

C1-C8

C6-C8

C5-C8

White Signal Reference

5 V

5 V

5 V

Clear

Shield

G

7.4 Programming

Short Cut is the best source for up-to-date datalogger programming code.

Programming code is needed,

when creating a program for a new datalogger installation.

when adding sensors to an existing datalogger program.

If your data acquisition requirements are simple and you are connecting the

sensor to a pulse port, you can probably create and maintain a datalogger

program exclusively with Short Cut. If your data acquisition needs are more

complex, the files that Short Cut creates are a great source for programming

code to start a new program or add to an existing custom program.
